Secure both pedestal and bench style grinders securely to the floor or work bench to prevent movement during usage. Adjust tool rests to within 3 mm 18 in of wheels.

Safety And Health Topics Machine Guarding Checklist For

The wheel guard enclosure should cover most of the wheel the spindle and the wheel mounting hardware.

Bench grinder guard requirements. 215b9 is the adjustable tongue guard on the top side of the grinder used and kept to within 14 inch 06350cm of the wheel. 215a4 is the work rest used and kept adjusted to within 18 inch 03175cm of the wheel. There are four basic safety elements to the bench grinder that serve as guards or shields.

Fasten pedestal and bench grinders on a solid surface securely. Bench and floor stands. Discard used wheels once they are approximately 23 worn.

So here is an overview of a few important osha requirements you need to remember when operating these type grinders. The bench grinder safety gauge measures 2 34 inches wide by 2 14 inches high by 1000 inches thick and has a 14 inch hole for attachment to the bench grinder. Osha 29 cfr 1910215 specifies that work rests must be kept adjusted closely to the wheel with a maximum opening of 18 inch to prevent the workpiece from being jammed between the wheel and the rest.

First of all make certain the bench grinder is firmly secured to the work bench or other work surface per the manufacturers instructions. Workers should only be exposed to 90 degrees 75 percent or less of the grinding wheel unless more the type of work requires more exposure. I know you have to have side gaurds tool rest and eye sheilds on a bench grinder found out the hard way but what are the regulation for cloth buffing wheels.

This exposure shall begin at a point not more than 65 deg. Or one fourth of the periphery. The angular exposure of the grinding wheel periphery and sides for safety guards used on machines known as bench and floor stands should not exceed 90 deg.

Maintain 6 mm 14 in wheel exposure with a tongue guard or a movable guard. Do side guards cover the spindle nut and flange and 75 of the wheel diameter. Before i discard this old bench grinder the side gaurds were trown out years ago can i use it for buffing and or wire wheels.

Above the horizontal plane of the wheel spindle. Check the following before using your grinder. Guards must also protect workers from the grinding wheel.

If grinding work requires more than 90 degrees of exposure the maximum exposure amount is 125 degrees. Bench and pedestal grinders. Proper guarding is one of the most important safety requirements.

The eye shield is an optional protector for the worker who should be wearing eye protection. The flange and spindle guard protect the worker from the spinning wheel. Never adjust rests while wheels are moving.

Safety precautions when operating a pedestal or bench grinder. Missing or improperly adjusted guards are common and frequent safety violations. The adjustable tongue guard helps suppress flying debris and sparks.

Store grinding wheels carefully on racks in dry places and visually inspect them for warping chips cracks or other damage before installation. Ensure all the guards are in place and secure before using a grinder.
